HR2230
Rotary Hammer
HR2230
Rotary Hammer
Rotary Hammer 22 mm (7/8") 2.2 J, SDS-PLUS
๐ High durability in mechanical parts, motor and carbon brush ๐ 2.2 Joules (EPTA) impact energy delivers high performance ๐ 2 operation modes - hammering with rotation and rotation only ๐ Speed and torque in reverse are the same as forward rotation by using brush holder unit ๐ One-touch sliding chuck enables easy bit change ๐ Variable speed trigger allows operator to adjust speed based on materials or application ๐ Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection ๐ Ergonomically designed rubberized grip provides more control and comfort ๐ Side grip with elastomer soft grip ๐ Easy-to-operate large trigger switch and lock-on button ๐ Depth gauge for increased drilling consistency ๐ Double insulated
Standard Equipments : Side grip, Depth gauge
Technical specifications
| Continuous Rating Input | 710 W |
|---|---|
| Impact energy | 2.2 J |
| Capacity : Concrete | 22 mm |
| Capacity : Steel | 13 mm |
| Capacity : Wood | 32 mm |
| Blows Per Minute (BPM) | 09 - 4,050 |
| No Load Speed (RPM) | 0 - 1,050 |
| Dimensions (L x W x H) | 357 x 84 x 214 mm |
| Net weight | 2.6 - 3.1 kg |
| Carbon Brush | 325 |
