(EN / TH)

LF1000
Flip Over Saw

LF1000
Flip Over Saw

Flip Over Saw 260 mm (10-1/4")

  

๐ Miter saw and Table saw are combined for great versatility ๐ Tough motor ideal for cutting material with load, bevel cut (max. 45 degrees left), cutting thick material ๐ Compact fold away legs allow easy transport to job site ๐ Rigid cast aluminum table ๐ Lightweight for easy transport to job sites ๐ Dust bag for a cleaner work environment ๐ High Dust Collection Rate ๐ Electric brake for maximum productivity and increased operator safety ๐ Constant speed control allows for use of powerful, yet lightweight motor ๐ Soft start minimizes the breaker from tripping at job sites ๐ On-Off Switch with Anti-Restart Function ๐ Lock-off and lock-on functions ๐ Double insulated

Standard Equipments : Carbide-tipped saw blade, Rip fence, Miter gauge, Push stick, Top cover assy (Top blade guard), Dust cover, Dust bag, Wrench


Technical specifications

Continuous Rating Input 1,650 W
Max Cutting Capacity 20, 68 x 155, 210 mm
Max Cutting Capacity 45° 50 x 150 mm
Wheel Diameter 260 mm
Hole diameter 30 / 25.4 mm
No Load Speed (RPM) 2,700
Dimensions (L x W x H) 660 x 650 x 1,220 mm
Net weight 36 kg
Carbon Brush 153
Double Insulation
Brake
Constant Speed
Soft Start
Bevel Cutting 45 left
Dust Collection
