4100NH2
Cutter

4100NH2
Cutter

Cutter 125 mm (5") 1,400 W, Dry / Wet Type

  

๐ Powerful 1,400 W motor delivers 12,200 RPM ๐ Bevel-cuts up to 45 degrees ๐ Up to 125 mm (5") diameter diamond wheel can be used ๐ Heavy duty aluminum gear housing for increased durability ๐ Water supply plug; Plastic is used for lightweight design ๐ Leading edge of baseplate indicates precise line of cut ๐ Cuts up to 40 mm (1-9/16") with 125 mm (5") wheel ๐ Powerful cutting in stone, masonry, tile, concrete & more ๐ Can be used with wet or dry type wheels ๐ Flat motor housing allows tool to stand upright when changing blades ๐ Easy to adjust depth gauge for precision cutting ๐ Large top handle design for increased comfort ๐ Dust proof switch and labyrinth construction minimizes contamination of motor ๐ Lock-off button helps minimize accidental starts ๐ Lock-on button for continuous use operation ๐ On-tool hex wrench for fast and easy blade changes and keeping it from lost

Standard Equipments: Diamond wheel , Water supply plug, Vinyl tube , Wrench, Hex wrench


Technical specifications

Continuous Rating Input 1,300 W
Wheel Diameter 110 mm
Max Cutting Capacity 32 mm
No Load Speed (RPM) 13,800
Dimensions (L x W x H) 238 x 214 x 169 mm
Net weight 2.8 kg
Carbon Brush 303
Double Insulation
Bevel Cutting 45 left
