(EN / TH)

DCC500
Cordless Dustless Cutter

DCC500
Cordless Dustless Cutter

18V Cordless Cutter 125 mm (5") Dry Type

  

๐ BL motor provides high power and excellent cutting performance ๐ Built-in LED light for better illumination and more accurate work ๐ Extreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions ๐ Auto-start Wireless System (AWS) connects to compatible vacuum cleaners with Bluetooth ๐ Automatic torque Drive Technology (ADT) adjusts cutting speed and torque during cut for optimum performance ๐ 360° rotatable dust collecting port for vacuum cleaner / dust bag Connection ๐ Compatible with optional guide rail for increased maneuverability ๐ Dust cover to minimize dust scattering around ๐ Dust proof switch covered with dust cover minimizes contamination of motor ๐ Up to 125 mm (5") diameter diamond wheel can be used ๐ Cuts up to 40 mm (1-9/16") with 125 mm (5") wheel ๐ Powerful cutting in stone, masonry, tile, concrete & more ๐ Lock-on button for continuous use operation (for tool with lock-on button) ๐ Two-stage safety trigger switch minimizes accidental start up (for tool with lock-off button) ๐ On-tool hex wrench for fast and easy blade changes and keeping it from lost. ๐ Battery protection circuit protects against overloading, over-discharging and over-heating

Standard Equipments: DUST BAG ASSEMBLY 126738-0(1) HEX. WRENCH 5 783217-7(1)


Technical specifications

Blade diameter 125 mm
Hole diameter 20 mm
Max Cutting Capacity 40 mm
Max Cutting Capacity 45° 27 mm
No Load Speed (RPM) 8,800
Dimensions (L x W x H) 231 x 158 x 172 mm
Net weight 2.5 - 3.0 kg
Brake
Soft Start
Bevel Cutting 45 left
Dust Collection
Built-in-Job Light
