DML819
Cordless Magnetic Light

DML819 Parts List (0.71 MB)

DML819 Leaflet (19.14 MB)

DML819
Cordless Magnetic Light

18V LXT Li-Ion LED Magnetic Light, 1,200 Lumens

  

Features

  • When performing maintenance work on construction machinery or heavy equipment, the tool can be attached and fixed to ferrous metal parts with the magnet, allowing for hands-free work.
  • Without losing high brightness illumination at hand, this worklight is engineered so compact and so handy to hold with one hand that it can be attached easily to tight spaces.
  • Max luminous flux: 1,200 lm
    - High/Medium/Low: 1,200/800/500 (lm)
    - Sufficient lighting time even at maximum luminous flux
  • Compact design; This model is superior to our current worklight models and competitors' models in saving space both in usage and storage, because they are engineered with a minimum body size required to achieve a maximum luminous flux of 1,200 lm.
  • Lightweight design: 1.2 kg with BL1815N, 1.6 kg with BL1860B, 2.2 kg with BL18120
  • Diffusing lens reduces verlapping shadows and glare to reduce strain on the eyes.
  • Foldable rotating LED head
    - 180° vertical
    - 300° horizontal (90°right/210°left)
  • Magnetic bars are embedded in the bottom face which can be fixed to ferrous metals.
  • Magnet cover (Standard equipment):
    - Magnetic bars can be covered with Magnet cover for anti-adherence of ferrous metals such as iron powder, screws, etc.
    - Can be used also as a handy portable worklight, with the cover closed for reduced magnetic force.
    - Can be stored on the back of the light
  • Handle with a shape that is easy to hold and pull when removing the worklight fixed with the magnet
  • Battery capacity warning function: When the battery is getting close to empty, this function will warn user by disabling 11 out of 12 LEDs to light up only one LED, which will turn off after 5 minutes.
  • Gradual illumination relieves the stress on user's eyes.

Standard equipment : Magnet cover


Parts List
(0.71 MB)


Leaflet
(19.14 MB)

Technical specifications

Continuous use High / Med. / Low : BL1860B : 9 / 14 / 22 hours
Illuminance (High / Med. / Low) 1,750 / 1,150 / 700 lx
Luminous flux (High / Med. / Low) 1,200 / 800 / 500 lx
Dimensions (L x W x H) 178 x 91 x 161 mm
Net weight 1.2 - 2.2 kg
