TD0100
Impact Driver
TD0100
Impact Driver
Impact Driver 100 N･m
Features
๐ Impacting mechanism for secure fastening
๐ Compact and lightweight
๐ No harm to the wrist when a screw is seated
๐ Enables to drive screws even without pre-drilling pilot holes
๐ Can Be Used For Any Light Fastening Applications
๐ Compact bit sleeve
๐ Easy to operate forward and reverse change lever
๐ Ergonomic soft rubber grip for vibration absorption and comfortable operation
๐ Electric brake for increased productivity
๐ Double insulated
Standard Equipments : Phillips bit
Technical specifications
| Continuous Rating Input | 230 W |
|---|---|
| Capacity Machine screw | M4 - M8 |
| Capacity Standard bolt | M5 - M14 |
| Capacity High strength bolt | M5 - M10 |
| Capacity : Steel | 22 mm |
| Driving shank (Hex) | 6.35 mm |
| No Load Speed | 0 - 3,600 minˉ¹ |
| Impacts Per Minute | 0 - 3,200 minˉ¹ |
| Max fastening torque | 100 N·m |
| Dimensions (L x W x H) | 218 x 60 x 180 mm |
| Net weight | 0.96 kg |
| Carbon Brush | 419 |
