TW004G
Cordless Impact Wrench
40V Max 1/2" 350 N·m (260 ft.lbs.) Impact Wrench
Other Products
๐ Increased motor speed under load delivers higher torque than DTW300 and DTW301 ๐ Electronic 4 stage impact power selection for added versatility ๐ 3 modes of reaction time for automatic stop available both in forward and reverse rotation modes ๐ Trigger switch with full speed mode allows for less hand and finger fatigue ๐ Compact design with a short overall length of 144 mm ๐ Constant speed control maintains fastening torque by minimizing the rotation speed reduction caused by decreased battery capacity ๐ Style of socket retention: C ring
Standard Equipments: Belt Clip Any accessories shown are not necessarily supplied as standard equipment.
Information & Technologies
Technical specifications
| Fastening Capacities Standard Bolt | M10 - M20 (3/8 - 3/4") |
|---|---|
| Fastening Capacities High Strength bolt | M10 - M16 (3/8 - 5/8") |
| Square Drive | 12.7 mm (1/2") |
| No Load Speed (RPM) | Max / Hard / Mid / Soft : 3,200 / 2,600 / 1,800 / 1,000 |
| Impacts per minute (IPM) | Max / Hard / Mid / Soft : 4,000 / 3,400 / 2,600 / 1,800 |
| Max Fastening Torque | 350 N·m (260 ft.lbs.) |
| Dimensions (L x W x H) | 144 x 86 x 253 mm |
| Net weight | 1.9 - 2.2 kg (4.2 - 4.9 lbs.) |
| XGT : Next Generation Technology | ✓ |
| BL Motor | ✓ |
| XPT | ✓ |
| Variable Speed | ✓ |
| Brake | ✓ |
| Reversing | ✓ |
| Electronic 4-Speed | ✓ |
| Constant Speed | ✓ |
| Built-in Job Light | ✓ |
| Carrying Case | ✓ |
